RIFLESCO PE

MOA Subtensions

The EBR-1 reticle is based on minute-of-angle (MOA) subtensions.
MOA measurements are based on degrees
and minutes: 360 degrees in a circle, 60
minutes in a degree for a total of 21,600
minutes. These angular measurements
are used to estimate range and correct for
bullet trajectory drop in riflescopes. 1 MOA
will correspond to 1.05 inches at a 100
yard distance, 2.1 inches at 200 yards, 3.15
inches at 300 yards, and so on.

EBR-1 MOA Reticle Subtensions

In the Viper PST second focal plane
riflescopes, the listed MOA subtensions
of the EBR-1 reticle are only valid at
the highest magnifications of the scope.
However, by understanding the relationship
of magnification and subtensions,
ranging, holdovers, and wind drift can still be calculated at partial
magnifications. Here are some examples:
• If the magnification is set at ½ the full magnification, subtension
values will be two times the spec listed in the manual.

• If the magnification is set at

1/3

the full magnification, subtension

values will be three times the spec listed in the manual.

Fx-7400G PLUS User’s Guide CASIO COMPUTER CO., LTD. 6-2, Hon-machi 1-chome Shibuya-ku, Tokyo 151-8543, Japan. Connector SB-62 Power Graphic Unit to Power Graphic Unit.No part of this manual may be reproduced in any form without the express written consent of the. View and Download Casio FX-7400G PLUS user manual online. FX-7400G PLUS Calculator pdf manual download. Also See for Casio FX-7400G PLUS. CASIO fx-7400G PLUS User Manual 110 pages. Casio fx-7400G. Chapter Graphing A collection of versatile graphing tools plus a large 79 × 47-dot display makes it easy to draw a variety of function graphs. View and Download CASIO FX-7400G PLUS user manual online. FX-7400G PLUS Calculator pdf manual download. CASIO FX-7400G PLUS User Manual. Page 2 Power Graphic Unit to Power Graphic Unit Connector FA-123 Power Graphic Unit to PC for IBM/Macintosh Machine Declaration of Conformity Model Number: fx-7400G PLUS Trade Name: CASIO. Oct 14, 2018  CASIO FX-7400G PLUS MANUAL EPUB DOWNLOAD - fxG Manual. BEFORE USING THE CALCULATOR FOR THE FIRST TIME (MB). Chapter 1 Getting Acquainted (MB). Chapter 2 Basic. User manual, users manuals, user. View and Download CASIO Fx-7400G PLUS user manual online. Casio Calculator. Fx-7400G PLUS Calculator pdf manual download. Casio power graphic fx-7400g plus user manual.

• If the magnification is set at ¼ the full magnification, subtension
values will be four times the spec listed in the manual.

Although 1 MOA is very
commonly corresponded to
1 inch at 100 yards, this is
not quite correct. 1 MOA
at 100 yards equals 1.05
inches. Calling 1 MOA
an inch per 100 yards may
be acceptable at shorter
distances, but it will cause a
five percent error in ranging
and holdover adjustments.
This will result in missed
shots at longer distances.

Estimating MOA

Heavy crosshair
subtends 1 MOA

Fine crosshair
subtends .06 MOA

Gap subtends
1MOA

2.5 MOA

1 MOA

6–24x50 Reticle Subtensions

(Valid at 24x)

R

iflescope

M

agnification

24x
12x
8x
6x

1 MOA
2 MOA
3 MOA
4 MOA

a

Ebr 4 Moa Reticle

ctual

s

ubtension

of

1 Moa R

eticle

s

pace

Subtension Changes with Magnification

The Vortex

®

EBR-1 MOA Reticle

3

Vortex Ebr 4 Moa Reticle

RIFLESCO PE

Designed to maximize long distance shooting and ranging abilities, the
EBR-1 MOA reticle for the Viper®PST

TM

6–24x50 riflescope can be

used to effectively determine ranges, holdovers, windage corrections and
moving target leads. Ultra precision laser etching on the glass reticle
ensures that minute of angle (MOA) specifications can be kept to the
tightest tolerances possible. The fine center crosshair subtensions on
the EBR-1 MOA reticle were carefully chosen to provide the optimum
balance between precision aiming and low light visibility.

Note: Reticle images shown in this manual are for representation
only—images vary between scope models depending on magnification
and reticle plane.

Dual Use: Shooting Tactical / Hunting
US Patent 7,937,879
